LM Guideways (Linear Motion Guideways)
Product Overview
LM guideways are precision linear rails and blocks that ensure smooth, low-friction motion in automation systems. Essential for CNC machines, 3D printers, and semiconductor manufacturing.
Detailed Specifications
Rail Types
Standard Roller Guides
- Sizes: 15mm × 30mm to 45mm × 90mm.
- Load Capacity: 10kN (dynamic) to 30kN (static).
Ball Screw Guides
- Lead: 5mm, 10mm, 20mm.
- Accuracy: C3 (±0.05mm / 300mm).
Material
- Rails: SUJ2 bearing steel, hardened to 60 HRC.
- Blocks: Aluminum alloy (ADC12) with stainless steel balls.
Preload Levels
Light (0.02mm), medium (0.05mm), heavy (0.1mm).
Applications
- Semiconductor Wafer Handling:
- Automated Assembly Lines:
- Medical Imaging:
Features:
- Self-Aligning Blocks: Compensate for mounting surface irregularities.
- Lubrication Ports: Grease nipples for easy maintenance.
- Modular Design: Rails can be joined end-to-end for extended travel.
