High-Speed Spindles for CNC Machines

Product Overview

High-speed spindles are precision-machined rotating assemblies used in CNC routers, engravers, and milling machines. Designed for Indian industrial conditions, they deliver consistent performance under heavy loads.

Detailed Specifications

Water-Cooled Spindles
- Model 125 / 7.5KW
  - Power: 7.5kW, Speed: 24,000 RPM.
  - Collet: ER32, Voltage: 380V, Frequency: 800Hz.
  - Runout: < 0.005mm, Weight: 18kg.
- Model 125 / 5.5KW
  - Power: 5.5kW, Speed: 24,000 RPM.
  - Collet: ER25, Voltage: 380V, Frequency: 400Hz.
Air-Cooled Spindles
- Model 3.5KW
  - Power: 3.5kW, Speed: 18,000 RPM.
  - Collet: ER20, Voltage: 220V, Frequency: 300Hz.
  - Noise: < 65 dB(A).
- Model 6.0KW
  - Power: 6.0kW, Speed: 18,000 RPM.
  - Collet: ER32, Voltage: 380V, Frequency: 300Hz.
Bearings
Hybrid ceramic bearings (grease-lubricated) for 20,000-hour lifespan.
Cooling System
- Water-cooled: Integrated pump (1.5L/min flow rate).
- Air-cooled: Aluminum fins with axial fan (120 CFM airflow).
