Worm Reduction Gearboxes for Industrial Automation

Product Overview

Worm gearboxes use a worm screw and wheel for high reduction ratios in compact sizes. Aluminum models are lightweight for textile machinery, while cast iron (CI) variants handle heavy loads in harsh environments like Indian foundries.

Assisting senior consultants in projects
Share best practices and knowledge.
Share best practices and knowledge.

We work with clients to integrate the flow of the customer experience across channels (e.g., face-to-face, telephone), opening up new lead sources, supporting sales for smaller-value transactions,and creating new models for service. We continuously provide new and practical perspectives on the evolving. Customer Decision Journey, and work with clients to make the deep, transformational changes needed to support new strategies and capability demands. Earn more interest and get flexible access to your savings.

Detailed Specifications

Aluminum Series (BOX 25–90):

Ratios: 10:1 to 60:1.
Torque: 50 Nm (BOX 25) to 1,200 Nm (BOX 90).
Weight: 4kg (BOX 25) to 45kg (BOX 90).

CI Series (BOX 110–150):

Ratios: 15:1 to 100:1.
Torque: 1,500 Nm (BOX 110) to 8,000 Nm (BOX 150).
Weight: 85kg (BOX 110) to 220kg (BOX 150).

Applications

Textile Machinery: Speed reduction in ring frames (Lakshmi Machine Works).
Pharma Mixers: Precise dosing in tablet compression machines.
Ceramic Kilns: Drives conveyor belts in tile manufacturing.

Features:

Cooling Fins: CI models include fins for heat dissipation (up to 50°C ambient).
Input Options: Solid shaft, hollow shaft, or IEC flanges (B5/B14).
Anti-Corrosion: Aluminum bodies anodized; CI bodies painted with epoxy.
